Colorlight X4S Synchronous LED Sender Box

Sale price$134.00


Novastar VX4S LED Video Processor Details

Novastar VX4S LED Video Processor is a professional LED display controller.

it also features in powerful front end processing, so it doesn’t need an external scalar.


Novastar VX4S Video Processor features

Input Power AC100~240VAC,50/60Hz
Overall Power Consumption 25W
Operating Temperature -20~60℃
Dimensions 482.6mm × 251.5mm × 45mm
Package dimensions 550mm × 400mm × 175mm
Net weight 2.55 Kg
Total weight 5.5 kg


  • The inputs of the VX4S include CVBS×2, VGA×2, DVI×1, HDMI×1 , DP×1 and SDI×1. They support input resolution up to 1920×1200@60Hz; the input images of VX4S can be zoomed point-to-point according to the screen resolution.
  • Provide seamless high-speed switching and fade-in/ fade-out effect so as to strengthen and display picture demonstration of professional quality.
  • The location and size of PIP can both beadjusted, which can be controlled at will.
  • Adopt the NovaStar G4 engine; the screen is stable and flicker free without scanning lines; the images are exquisite and have a good sense of depth.
  • Can implement white balance calibration and color gamut mapping based on different features of LEDs used by screens to ensure reproduction of true colors.
  • HDMI/external audio input.
  • 10bit / 8bit HD video source;
  • The loading capacity: 2.3 million pixels.
  • Support multiple controller montage for loading huge screen.
  • Support NovaStar’s new-generation point-by-point calibration technology; the calibration is fast and efficient.
  • Computer software for system configuration is not necessary. The system can be configured using one knob and one button. All operations can be done in a few steps. That’s what we call Easy Screen Configuration!
  • Adopt an innovative architecture to implement smart configuration; the screen debugging can be completed within several minutes; greatly shorten the preparation time on the stage.
  • An intuitive LCD display interface and clear button light hint simplify the control of the system.
