VDWALL LVP100 LED High Definition Video Processor


Price:
Sale price$195.00

Description

1. 4 inputs, 2 outputs, dual images, it’s enough for the application requirements to small LED in most cases

2. It allows an access to set the output resolution to fulfill the size of LED screen

3. DVI EDID make it possible to set the input resolution freely to make dot-to-dot display successful.

4. PIP / PBP display among any 2 images, 3 custom preset dual-images mode

5. Seamless switching, fade in and fade out switching

6. Control method: operations on front panel buttons, it’s convenient and flexible for front panel users

7. It is enabled to put 2 sending cards inside

8. It is enabled to work for seven days a week and twenty four hours a day. High-reliable and stable.



VDWALL LVP100 LED High Definition Video Processor Specifications:

Specification of OutputsOthers

Specification of Inputs
Quantity/Type 1×CVBS
1×VGARGBHV
1×DVIVESA
1×HDMIVESA/CEA-861
Composite Video
Input SYS
PAL / NTSC
Composite Video
Amplitude
Impedance
1V (p_p) / 75Ω
VGA Format  PC (VESA Standard)  ≤2048×1152_60Hz
VGA Amplitude
the impedance
RGB = 0.7 V(p_p) / 75Ω
DVI Format  PC (VESA Standard)  ≤2304×1152_60Hz
HDMI Format PC (VESA Standard)  ≤1920×1080_60Hz
HDMI1.3 (CEA-861)  ≤1080p_60Hz
Input Interface CVBS: BNC
VGA: 15pin D_Sub (Female)
DVI: 24+1 DVI_D(Female)
HDMI: Type-A HDMI port
Quantity / Type  2×DVI
DVI Format 1024×768_60Hz/75Hz
1080×1920_60Hz
1200×1600_60Hz
1280×1024_60Hz/75Hz
1600×1200_60Hz-
1920×1080_50Hz/60Hz-
1366×768_60Hz-
1440×900_60Hz-
1536×1536_60Hz-
1920×1200_60Hz2048×1152_60Hz
2304×1152_60Hz
2560×816_60Hz2048×1152_60Hz
2304×1152_60Hz
2560×816_60Hz
Output Interface  DVI OUT24+1 DVI_D
Control Ports  RS232 (Optional)
Voltage of Input  100-240VAC 50/60Hz
Power
Consumption
≤25W
Temperature of
Environment
0-45
Humidity of
Environment
15-85%
Size of Product  482.6 (L) x 200 (W) x 44 (H)mm
Packing Size  535 (L) x 315 (W) x 145 (H)mm
Weight  G.W.: 4Kg, N.W.: 2.5Kg
Standard
accessories
1.5m power cord ×1 1.5m DVI cable ×1
User manual ×1 operations CD ×1 BNC-RCA adapter ×1
Optional
accessories
LED sending cards×2



VDWALL LVP100 LED High Definition Video Processor Connection Diagram:



VDWALL LVP100 LED High Definition Video Processor



VDWALL LVP100 LED High Definition Video Processor Product Dimension:



VDWALL LVP100 LED High Definition Video Processor

VDWALL LVP100 LED High Definition Video Processor



More Pictures of VDWALL LVP100 LED High Definition Video Processor:

VDWALL LVP100 LED High Definition Video Processor

VDWALL LVP100 LED High Definition Video Processor

VDWALL LVP100 LED High Definition Video Processor

VDWALL LVP100 LED High Definition Video Processor

VDWALL LVP100 LED High Definition Video Processor
